Electric Slab Scissor Lift

FSJY Aerial Work Platform

Mobile elevating work platform with 300kg capacity, up to 9100mm working height

For demanding indoor maintenance and outdoor high-altitude tasks, the electric slab scissor lift stands out with its spacious platform and exceptional load capacity. Its ability to safely support more poeple and tools makes it a reliable choice for enhancing efficiency and versatility across diverse applications.

300kg
9100mm

Request a Quote

Specifications

Model Number	Unit	FSJY6	FSJY8
Max. Platform Height	mm	6000	8000
Max. Working Height	mm	7100	9100
Min. Platform Height	mm	1080	1200
Ground Clearance	mm	20	20
Rated Lift Capacity	kg	300	300
Platform Extend Capacity	kg	100	100
Platform Size	mm	1880×900
Platform Extend Length	mm	900
Max. Drive Speed (Platform Stowed)	km/h	3-4
Max. Drive Speed (Platform Elevated)	km/h	0.6-1
Min. Turning Radius	mm	2000
Max. Gradeability	%	10-15
Driving Wheel Size	mm	Ø305×100
Steering Wheel Size	mm	Ø305×100
Driving Motor	V/kW	2×24/0.5
Lifting Motor	V/kW	24/2.2
Battery	V/Ah	2×12/150
Charger	V/A	24/25
Pothole Protection System		Mechanical control
Overall Length	mm	2050
Overall Width	mm	900
Overall Height (Guardrail Folded)	mm	1735		1860
Overall Net Weight	kg	1500		1700

Features

Equipped with a buzzer and flashing warning lights to alert nearby personnel during operation
The foot-pedal controlled platform extension can be quickly expanded to the work area, providing a larger operational range.
Folding guardrails reduce the overall machine size, enabling it to pass through low-height spaces easily.
Error code display simplifies maintenance by quickly identifying issues for easy troubleshooting.
Includes an automatic pothole protection system and a tilt sensor, ensuring maximum safety during operation.
Both ground and platform operators can activate emergency stop buttons to immediately halt platform movement in case of malfunction.
Safety maintenance support bar protects maintenance personnel during inspections and repairs, ensuring secure and safe maintenance operations.

Main Options

Standard Features

Automatic brake
Buzzer
Platform extension
Automatic pothole protection
Emergency lowering system
Battery indicator
Horn
Battery charging protection
Self-closing platform gate
Emergency stop button
Hour meter

Electric drive system
Safety maintenance support bar
Folding guardrails
Fault diagnosis system
Standard forklift pockets
Signal light
Tilt sensor
Maintenance-free battery

Optional Features

Lithium battery
